Works With You
- Supports code branching and merging
- Supports multiple developers
- Supports multiple database types
- Supports XML, YAML, JSON and SQL formats
- Supports context-dependent logic
- Cluster-safe database upgrades
- Generate Database change documentation
- Generate Database "diffs"
- Run through your build process, embedded in your application or on demand
- Automatically generate SQL scripts for DBA code review
- Does not require a live database connection
Get Started
- Download Liquibase
- Create new changelog file in XML, YAML, JSON or SQLformat
- Add changeset to changelog file
- Run liquibase update
- Commit changelog file to source control
- GOTO 3
Read More
Refactor Your Database
- Simple commands like Create Table and Drop Column
- Complex commands like Add Lookup Table and Merge Columns
- Specify the exact SQL to run
- Plus the ability to Generate and manage rollback logic
Open and Extensible
- Open Source: Apache 2.0 License
- Extension support allows you to extend and override virtually every part of Liquibase
- Java APIs for executing and embedding
<?xml version="1.0" encoding="UTF-8"?>
<databaseChangeLog
xmlns="http://www.liquibase.org/xml/ns/dbchangelog"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:ext="http://www.liquibase.org/xml/ns/dbchangelog-ext"
xsi:schemaLocation="http://www.liquibase.org/xml/ns/dbchangelog http://www.liquibase.org/xml/ns/dbchangelog/dbchangelog-3.1.xsd
http://www.liquibase.org/xml/ns/dbchangelog-ext http://www.liquibase.org/xml/ns/dbchangelog/dbchangelog-ext.xsd">
<preConditions>
<runningAs username="liquibase"/>
</preConditions>
<changeSet id="1" author="nvoxland">
<createTable tableName="person">
<column name="id" type="int" autoIncrement="true">
<constraints primaryKey="true" nullable="false"/>
</column>
<column name="firstname" type="varchar(50)"/>
<column name="lastname" type="varchar(50)">
<constraints nullable="false"/>
</column>
<column name="state" type="char(2)"/>
</createTable>
</changeSet>
<changeSet id="2" author="nvoxland">
<addColumn tableName="person">
<column name="username" type="varchar(8)"/>
</addColumn>
</changeSet>
<changeSet id="3" author="nvoxland">
<addLookupTable
existingTableName="person" existingColumnName="state"
newTableName="state" newColumnName="id" newColumnDataType="char(2)"/>
</changeSet>
</databaseChangeLog>databaseChangeLog:
- preConditions:
- runningAs:
username: liquibase
- changeSet:
id: 1
author: nvoxland
changes:
- createTable:
tableName: person
columns:
- column:
name: id
type: int
autoIncrement: true
constraints:
primaryKey: true
nullable: false
- column:
name: firstname
type: varchar(50)
- column:
name: lastname
type: varchar(50)
constraints:
nullable: false
- column:
name: state
type: char(2)
- changeSet:
id: 2
author: nvoxland
changes:
- addColumn:
tableName: person
columns:
- column:
name: username
type: varchar(8)
- changeSet:
id: 3
author: nvoxland
changes:
- addLookupTable:
existingTableName: person
existingColumnName:state
newTableName: state
newColumnName: id
newColumnDataType: char(2){
"databaseChangeLog": [
{
"preConditions": [
{
"runningAs": {
"username": "liquibase"
}
}
]
},
{
"changeSet": {
"id": "1",
"author": "nvoxland",
"changes": [
{
"createTable": {
"tableName": "person",
"columns": [
{
"column": {
"name": "id",
"type": "int",
"autoIncrement": true,
"constraints": {
"primaryKey": true,
"nullable": false
},
}
},
{
"column": {
"name": "firstname",
"type": "varchar(50)"
}
},
{
"column": {
"name": "lastname",
"type": "varchar(50)"
"constraints": {
"nullable": false
},
}
},
{
"column": {
"name": "state",
"type": "char(2)"
}
}
]
}
}
]
}
},
{
"changeSet": {
"id": "2",
"author": "nvoxland",
"changes": [
{
"addColumn": {
"tableName": "person",
"columns": [
{
"column": {
"name": "username",
"type": "varchar(8)"
}
}
]
}
}
]
}
},
{
"changeSet": {
"id": "3",
"author": "nvoxland",
"changes": [
{
"addLookupTable": {
"tableName": "person",
"existingTableName": "person",
"existingColumnName":"state",
"newTableName": "state",
"newColumnName": "id",
"newColumnDataType": "char(2)",
}
}
]
}
}
]
}--liquibase formatted sql
--changeset nvoxland:1
create table person (
id int not null primary key,
firstname varchar(80),
lastname varchar(80) not null,
state varchar(2)
);
--changeset nvoxland:2
alter table person add column username varchar(8)
--changeset nvoxland:3
create table state AS SELECT DISTINCT state AS id FROM person WHERE state IS NOT NULL;
alter table state modify id char(2) NOT NULL;
alter table state add primary key(id);
alter table person add constraint fk_person_state foreign key (state) references state(id);
